CMX 51.2V 660Ah LiFePO4 Battery for Mini Forklift and Electric Vehicle
The CMX 51.2V 660Ah LiFePO4 Battery for Mini Forklift and Electric Vehicle is a LiFePO4 battery for electric forklifts. Engineered for long service life, a protected smart BMS, and safe, low-maintenance operation.
- 51.2V · 660Ah
- 6000+ cycle life · 5-year warranty
- Agriculture/Marine: Long endurance, resistant to harsh environments, and stable power output to ensure prolonged and efficient operations.
- Marine: Waterproof and anti-corrosion, safe and reliable, with strong power to guarantee stable navigation on water.
Overview
The CMX 51.2V 660Ah LiFePO4 Battery for Mini Forklift and Electric Vehicle is a drop-in lithium iron phosphate (LiFePO4) power pack engineered for small electric forklifts, walkie stackers, pallet trucks, and light electric vehicles. Rated at 51.2V (16-series LiFePO4) with a 660Ah capacity, it delivers about 33.8 kWh of usable energy in a sealed, space-saving enclosure that replaces bulky, high-maintenance lead-acid batteries without changing the compartment or charger footprint in most applications.
CMX builds the pack from automotive-grade LiFePO4 cells and a self-developed smart BMS. The result is a battery that stays balanced, runs cool, and is protected across its whole service life — so operators get flat voltage through discharge, fast opportunity charging, and far less downtime than lead-acid.
Key Features
- Drop-in lead-acid replacement — same nominal voltage and a compact form factor that fits standard mini-forklift and pallet-truck battery compartments; 100% usable capacity with no watering, equalizing, or acid handling.
- Long service life — 3,500+ cycles at 80% depth of discharge, far beyond the 500–1,000 cycles typical of lead-acid, lowering the cost per cycle over the equipment’s life.
- Smart BMS with full protection — over-voltage, under-voltage, over-current, short-circuit, and over/under-temperature protection plus automatic cell balancing keep every cell within safe limits.
- Fast & opportunity charging — supports opportunity charging during breaks, removing the long equalize cycles lead-acid requires and extending daily uptime.
- Flat discharge curve — LiFePO4 holds voltage near nominal through most of the discharge, so the forklift or EV keeps full power until the pack is nearly empty.
- Built for industrial use — sealed, vibration-resistant enclosure, low self-discharge, and stable output from cold-start to high-temperature operation, with low-temperature charging protection.
Technical Specifications
| Nominal Voltage | 51.2V (16S LiFePO4) |
|---|---|
| Nominal Capacity | 660Ah |
| Energy | ≈ 33.8 kWh |
| Battery Chemistry | LiFePO4 (lithium iron phosphate) |
| Cycle Life | 3,500+ cycles at 80% DoD |
| BMS | Smart BMS: over/under-voltage, over-current, short-circuit & temperature protection, cell balancing |
| Communication | CAN bus / RS485 for forklift & host integration |
| Enclosure | Sealed, vibration-resistant industrial enclosure |
| Certifications | UL 1973, IEC 62619, UN 38.3, CE, and RoHS |
| OEM/ODM | Custom voltage, capacity, BMS, and enclosure available |
Full mechanical drawings, dimensions, weight, and discharge curves are available in the downloadable datasheet — contact CMX for the complete specification.
Application Scenarios
The 51.2V 660Ah LiFePO4 pack is purpose-built for electric material-handling and light electric-mobility equipment, including:
- Mini forklifts & walkie stackers — direct lead-acid replacement for small warehouse and retail forklifts that run multiple shifts.
- Electric pallet trucks & tow tractors — a compact, low-weight pack that improves maneuverability while extending run time per charge.
- Low-speed electric vehicles — neighborhood EVs, electric utility carts, and groundskeeping vehicles needing a safe, maintenance-free 51.2V power source.
- AGV & automated guided vehicles — stable, fast-charging power for automated warehouses and production lines.
- Electric golf carts & airport / campus tugs — reliable daily-service energy with opportunity charging between runs.
Because it is a 51.2V LiFePO4 system with a protected smart BMS, the pack is also a strong base for custom OEM/ODM electric-vehicle and material-handling projects — see our forklift & AGV LiFePO4 OEM guide or contact CMX to size a configuration for your equipment.
Why Choose Shenzhen CMX Battery Co., Ltd.
Shenzhen CMX Battery Co., Ltd. is a 9+ year LiFePO4 battery manufacturer with an annual cell-and-pack capacity of 5.8 GWh and an in-house factory in Tangxia, Dongguan, China. We provide OEM/ODM for voltage, capacity, BMS, and enclosure, and every pack ships with certified cells (UL 1973, IEC 62619, UN 38.3, CE, and RoHS). Our engineering team supports system sizing, standard BMS communication, and global compliance so integrators and distributors can deploy with confidence.
FAQ
Can it replace my forklift lead-acid battery?
Yes. The 51.2V 660Ah pack is built as a drop-in forklift battery with 100% usable capacity.
How much runtime do I gain?
LiFePO4 keeps voltage flat through discharge and supports opportunity charging, extending daily uptime versus lead-acid.
Get a Quote & Datasheet
Need pricing, lead time, or the full specification for the CMX 51.2V 660Ah LiFePO4 Battery for Mini Forklift and Electric Vehicle? Our team replies with a quote, OEM/ODM options, and the downloadable datasheet. You can also reach us at sales@cmxbattery.com.
You must be logged in to post a review.
Product & Packaging Details
Q: Do batteries include protection circuits(BMS) and connectors?
A:Protection: We supply batteries with BMS built in Protection Circuit Modules (PCM).
Connectors: We normally use standard like anderson,M8 lugs,Fast plugs or depends on OEM customer's demands.
Q: Are batteries Grade-A and brand new?
A: Yes, we use 100% brand new, Grade-A cells in all our batteries.
Q: Can you print our logo on the batteries?
A: Yes, we offer free custom logo printing with a minimal MOQ requirement.
Q: What is your standard packaging? Can it be customized?
A: Our standard is a white box per battery. We fully support customized packaging, including carton box and logo design.
Yes. CMX Battery is a manufacturer located in Shenzhen, Guangdong, China. It designs and produces LiFePO4 battery packs for energy storage, electric forklifts, marine applications, golf carts, RVs, and UPS systems.
Lead time depends on the product: standard battery packs are typically 15-25 days, while larger integrated systems such as our mobile EV charging units are 35-45 days. The exact schedule is confirmed in your quotation.
The company has strategic cooperation agreements with top manufacturers like EVE and REPT, and insists on using A+ tier One lithium iron phosphate cells for its solar batteries.
For 48V inverters, compatible brands include Victron Energy, Goodwe, Studer, Solis, LuxPower, and others. For high-voltage three-phase inverters, compatible brands include Atess, Solinteg, SAJ, Goodwe, and Solis.
CMX Battery offers dealer customers a 10-year warranty and technical service for its energy storage battery products.
DoD describes how much of the battery's capacity has been used. A DoD of 100% means the battery is completely empty, while 0% means it is full.
SoC reflects the battery's charge level. A SoC of 100% means the battery is full, and 0% means it is empty.
C-rate, or power factor, indicates how quickly a battery can be charged or discharged relative to its capacity. A rating of 1C means the battery can be fully charged or discharged in one hour.
The battery uses Lithium Iron Phosphate chemistry and provides a cycle life of over 6,000 cycles at 90% Depth of Discharge, and over 10 years at one cycle per day.
kW (kilowatt) is a unit of power, measuring the rate of energy production or consumption. kWh (kilowatt-hour) is a unit of energy, measuring the total amount of work done or energy used over time.
CMX Battery home batteries are suitable for both indoor and outdoor installation (depending on the model's protection level) and offer floor-standing or wall-mounted options. Common locations include garages, attics, or under eaves.
This depends on the load. As a realistic example, a 10kWh battery could run ten 100-watt light bulbs for 12 hours without recharging.
The number varies based on home size, energy consumption history, and personal goals (like which devices to run during an outage). For most systems, 2 or 3 batteries are installed. A detailed discussion of your needs is recommended for an accurate assessment.
Yes, it is possible, but it requires careful planning and significant investment. A true off-grid system needs a large enough solar array and sufficient battery storage to sustain your lifestyle. Cost and having an alternative energy source for when solar charging isn't possible are key considerations.
No. CMX Battery focuses on building long-term relationships with business partners like battery distributors, solar equipment dealers, and installation contractors worldwide, not direct sales to end consumers.
