CMX 12.8V 200Ah 2.56kWh LiFePO4 Battery for RV and Golf Cart

The CMX 12.8V 200Ah 2.56kWh LiFePO4 Battery for RV and Golf Cart is a LiFePO4 battery for RV, golf cart, and solar lead-acid replacement. Engineered for long service life, a protected smart BMS, and safe, low-maintenance operation.

12.8V · 200Ah · 2.56kWh usable
6000+ cycle life · 5-year warranty
Highest-level Grade A+ LiFePO4 Battery provides 6000+ cycles (a 10-years lifetime), 8 times more than lead-acid batteries.
Built-in 120A BMS, Support 1C fast charging and discharging, to protect from overcharging & discharging, over current, short circuit, and over temp.

SKU: CMX2107581FS Category: Golf cart Lithium Battery

Description

Overview

The CMX 12.8V 200Ah 2.56kWh LiFePO4 Battery for RV and Golf Cart is a LiFePO4 (lithium iron phosphate) battery built for RV, golf cart, and solar lead-acid replacement. It delivers 2.56kWh of usable energy · at 12.8V · with a rated 200Ah capacity, combining a long cycle life, a fully protected smart BMS, and a compact, space-saving design into a safe, maintenance-light energy storage solution. CMX uses automotive-grade LiFePO4 cells and a self-developed BMS so the pack stays balanced, efficient, and protected across its whole service life.

Key Features

Highest-level Grade A+ LiFePO4 Battery provides 6000+ cycles (a 10-years lifetime), 8 times more than lead-acid batteries.
Built-in 120A BMS, Support 1C fast charging and discharging, to protect from overcharging & discharging, over current, short circuit, and over temp.
Bluetooth and Heating function operational , Support RS485/CAN/RS232 communicate，Monitor battery status, optimize battery usage, and provide safety protection.
Durable, lightweight, and maintenance-free. Light weight 22 lbs only, it weighs only 1/3 of a 100Ah lead-acid battery (63.9 pounds).
Max 4P4S connection to reach up to 20.48kWh, enables flexible combinations for Solar system,RV, Van, camping, etc.

Technical Specifications

Nominal Voltage	12.8V
Nominal Capacity	200Ah
Usable Energy	2.56kWh
Battery Chemistry	LiFePO4 (lithium iron phosphate)
Cycle Life	Highest-level Grade A+ LiFePO4 Battery provides 6000+ cycles (a 10-years lifetime), 8 times more than lead-acid batteries.
Certifications	UL 1973, IEC 62619, UN 38.3, CE, and RoHS
OEM/ODM	Custom voltage, capacity, and enclosure available

Full mechanical drawings, dimensions, weight, and discharge curves are available in the downloadable datasheet — contact CMX for the complete specification.

Application Scenarios

This LiFePO4 pack is suited to drop-in lead-acid replacement for RVs, golf carts, and solar banks. It pairs with mainstream hybrid and off-grid inverters and scales from a single unit to parallel banks, making it a flexible choice for both first-time installs and capacity upgrades.

Why Choose Shenzhen CMX Battery Co., Ltd.

Shenzhen CMX Battery Co., Ltd. is a 9+ year LiFePO4 battery manufacturer with an annual cell-and-pack capacity of 5.8 GWh and an in-house factory in Tangxia, Dongguan, China. We provide OEM/ODM for voltage, capacity, BMS, and enclosure, and every pack ships with certified cells (UL 1973, IEC 62619, UN 38.3, CE, and RoHS). Our engineering team supports system sizing, standard BMS communication, and global compliance so integrators and distributors can deploy with confidence.

FAQ

Will it fit my existing battery tray?

The 12.8V/25.6V packs are sized as drop-in lead-acid replacements; confirm dimensions from the datasheet.

Can I mix it with my solar charge controller?

Yes. It works with common 12V/24V/36V/48V charging systems; set the LiFePO4 charging profile on your controller.

Get a Quote & Datasheet

Need pricing, lead time, or the full specification for the CMX 12.8V 200Ah 2.56kWh LiFePO4 Battery for RV and Golf Cart? Our team replies with a quote, OEM/ODM options, and the downloadable datasheet. You can also reach us at sales@cmxbattery.com.

Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “CMX 12.8V 200Ah 2.56kWh LiFePO4 Battery for RV and Golf Cart”

You must be logged in to post a review.

Support and Delivery

Check out the rechargeable lithium battery manufactuer production process

1000kWh Mobile BESS EV Charging Station for Emergency Power & Heavy-Duty Vehicle Fast Charging

Product & Packaging Details

Q: Do batteries include protection circuits(BMS) and connectors?
A:Protection: We supply batteries with BMS built in Protection Circuit Modules (PCM).

Connectors: We normally use standard like anderson,M8 lugs,Fast plugs or depends on OEM customer's demends.

Q: Are batteries Grade-A and brand new?
A: Yes, we use 100% brand new, Grade-A cells in all our batteries.

Q: Can you print our logo on the batteries?
A: Yes, we offer free custom logo printing with a minimal MOQ requirement.

Q: What is your standard packaging? Can it be customized?
A: Our standard is a white box per battery. We fully support customized packaging, including carton box and logo design.

Is CMX Battery a Lithium Battery manufacturer?

Yes. CMX Battery is a manufacturer located in Shenzhen, Guangdong, China. It designs and produces LiFePO4 battery packs for energy storage, electric forklifts, marine applications, golf carts, RVs, and UPS systems.

What is the production lead time?

Based on automated production technology, the current product lead time is 15-25 days.

Which battery cells does CMX Battery use?

The company has strategic cooperation agreements with top manufacturers like EVE and REPT, and insists on using A+ tier One lithium iron phosphate cells for its solar batteries.

Which inverters are compatible with CMX Battery batteries?

For 48V inverters, compatible brands include Victron Energy, Goodwe, Studer, Solis, LuxPower, and others. For high-voltage three-phase inverters, compatible brands include Atess, Solinteg, SAJ, Goodwe, and Solis.

What is the warranty for CMX Battery energy storage batteries?

CMX Battery offers dealer customers a 10-year warranty and technical service for its energy storage battery products.

What is Depth of Discharge (DoD)?

DoD describes how much of the battery's capacity has been used. A DoD of 100% means the battery is completely empty, while 0% means it is full.

What is State of Charge (SoC)?

SoC reflects the battery's charge level. A SoC of 100% means the battery is full, and 0% means it is empty.

What is C-rate?

C-rate, or power factor, indicates how quickly a battery can be charged or discharged relative to its capacity. A rating of 1C means the battery can be fully charged or discharged in one hour.

What is the cycle life of a CMX Battery Lithium Solar Battery?

The battery uses Lithium Iron Phosphate chemistry and provides a cycle life of over 6,000 cycles at 90% Depth of Discharge, and over 10 years at one cycle per day.

What is the difference between kW and kWh?

kW (kilowatt) is a unit of power, measuring the rate of energy production or consumption. kWh (kilowatt-hour) is a unit of energy, measuring the total amount of work done or energy used over time.

Where can a home battery be installed?

CMX Battery home batteries are suitable for both indoor and outdoor installation (depending on the model's protection level) and offer floor-standing or wall-mounted options. Common locations include garages, attics, or under eaves.

How long can a 10kWh Powerwall run home appliances during a power outage?

This depends on the load. As a realistic example, a 10kWh battery could run ten 100-watt light bulbs for 12 hours without recharging.

How many home batteries does my house need?

The number varies based on home size, energy consumption history, and personal goals (like which devices to run during an outage). For most systems, 2 or 3 batteries are installed. A detailed discussion of your needs is recommended for an accurate assessment.

Can I go completely off-grid with solar and batteries?

Yes, it is possible, but it requires careful planning and significant investment. A true off-grid system needs a large enough solar array and sufficient battery storage to sustain your lifestyle. Cost and having an alternative energy source for when solar charging isn't possible are key considerations.

Is CMX Battery an online store?

No. CMX Battery focuses on building long-term relationships with business partners like battery distributors, solar equipment dealers, and installation contractors worldwide, not direct sales to end consumers.
