32kWh 48V 628Ah Floor Mounted LiFePO4 Battery | Solar Home Energy Storage
The CMX Battery 32 kWh LiFePO4 solar home battery system is configured as two parallel 16 kWh units built with premium Grade-A EVE/CATL 51.2 V 16S 314 Ah cells, delivering reliable and scalable energy storage for residential use.
Its floor-mounted design and advanced Smart 200A BMS ensure over 9,000 cycles at 80 % depth of discharge (DOD), >95 % round-trip efficiency, and multiple safety protections—providing long lifespan, stable performance, and dependable home backup power for solar energy systems.
Introducing CMX Battery 32KWh LiFePO4 Battery Storage
The 32kWh 48V 628Ah floor mounted battery for house is a powerful, scalable energy storage system designed for residential solar applications.
It delivers reliable whole-home backup power by combining two high-performance 51.2V 314Ah LiFePO4 battery units in parallel (48V 32KWH / 2Sets*16KWh 314AH solar battery).
Built with premium EVE Grade A LiFePO4 cells, this 32KWH 48V 628Ah Renewable 51.2V lithium solar battery offers exceptional safety, long cycle life, and efficient energy management.
Whether you need a 32kwh lifepo4 energy storage system for home use or a robust solution for off-grid living, this floor-standing design provides stable power for essential appliances, lighting, and HVAC systems during outages or peak demand.
Perfect for homeowners seeking energy independence, this system stores excess solar energy during the day and supplies clean power at night or during grid failures.
Key Features & Benefits
- Massive 32kWh Capacity — Delivers true high-capacity storage ( 32.15kWh nominal) for extended home backup power.
- Grade A EVE LiFePO4 Cells — Pre-sale China Stock EVE Finished Battery Pack ensures superior thermal stability, safety, and longevity.
- Up to 9000+ Cycle Life — Significantly reduces long-term replacement costs compared to traditional batteries.
- Intelligent Active Balancing BMS — Real-time monitoring of voltage, current, temperature, and SOC with protections against overcharge, over-discharge, short-circuit, and thermal issues.
- Floor Mounted Design with Wheels — Easy installation and mobility for indoor use in garages, utility rooms, or storage areas.
- Maintenance-Free Operation — Low self-discharge rate and stable voltage output for worry-free performance.
- Scalable & Parallel Ready — Supports multiple units for even larger systems while maintaining compatibility with mainstream hybrid inverters.
This 32KWh floor mounted battery for house is eco-friendly, helping you maximize renewable energy utilization and lower electricity bills.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 32kWh Floor Mounted (2 × 16kWh units) |
| Battery Chemistry | LiFePO4 (Lithium Iron Phosphate) |
| Nominal Voltage | 51.2V (16S configuration) |
| Nominal Capacity | 628Ah / ~32.15kWh |
| Voltage Range | 40V – 58.4V |
| Charge/Discharge Current | Standard 150A / Max 200A (per unit) |
| Cycle Life | >9000 cycles (80% DoD) |
| Intelligent BMS Ensures Maximum Safety | 200A with active balancing |
| Communication | RS485, CAN |
| Display | Touchscreen / App monitoring |
| Mounting | Floor mounted with wheels |
| Operating Temperature | Charge: 0°C–45°C / Discharge: -10°C–50°C |
| Parallel Capability | Up to 15 units (expandable) |
| Weight & Dimensions | Heavy-duty cabinet (exact specs vary by configuration) |
Applications
- Home Solar Energy Storage System — Store daytime solar production for nighttime or cloudy days.
- Off-Grid Residential Power Supply — Ideal for remote homes or areas with unreliable grid access.
- Emergency Backup Power System — Keep critical loads running during blackouts.
- Residential Renewable Energy Management — Seamless integration for smart home energy optimization.
Installation & Compatibility
This 32KWh battery price reflects excellent value for a complete floor-mounted system. It is compatible with popular hybrid inverters including Growatt, Deye, Victron, Solis, GoodWe, SMA, Megarevo, Sunsynk, SolArk, and many others (confirm protocol compatibility). Recommended for indoor installation in garages, utility rooms, or dedicated energy storage spaces. Avoid direct sunlight, high humidity, or extreme temperatures.
Storage cabins
Garage energy storage rooms
Utility rooms
Frequently Asked Questions(FAQ)
Up to 9000+ cycles, providing 15–20+ years of reliable service depending on usage
Yes — designed specifically as a 32kwh lifepo4 energy storage system for home use and whole-house backup
Absolutely. Parallel multiple units for greater capacity.
Contact us for current wholesale pricing and pre-sale offers on the EVE cell-based pack
No, this is a maintenance-free lithium energy storage system
Supports indoor wall-mounted or floor-standing installation
Typically 10 years on the battery and BMS.
Inquiry for Wholesale Price
Ready to power your home with clean, reliable energy?
Contact us today for the latest 32KWh battery price, bulk/wholesale inquiries, or custom configuration details. We offer Grade A cells, flexible packaging, and strong support for global distributors and installers.
This 32KWH 48V 628Ah Renewable 51.2V lithium solar battery (Pre-sale China Stock EVE Finished Battery Pack) is your smart choice for sustainable home energy storage.
| Voltage |
|---|
Product & Packaging Details
Q: Do batteries include protection circuits（BMS) and connectors?
A:Protection: We supply batteries with BMS built in Protection Circuit Modules (PCM).
Connectors: We normally use standard like anderson,M8 lugs,Fast plugs or depends on OEM customer's demends.
Q: Are batteries Grade-A and brand new?
A: Yes, we use 100% brand new, Grade-A cells in all our batteries.
Q: Can you print our logo on the batteries?
A: Yes, we offer free custom logo printing with a minimal MOQ requirement.
Q: What is your standard packaging? Can it be customized?
A: Our standard is a white box per battery. We fully support customized packaging, including carton box and logo design.
Yes. CMX Battery is a manufacturer located in Shenzhen, Guangdong, China. It designs and produces LiFePO4 battery packs for energy storage, electric forklifts, marine applications, golf carts, RVs, and UPS systems.
Based on automated production technology, the current product lead time is 15-25 days.
The company has strategic cooperation agreements with top manufacturers like EVE and REPT, and insists on using A+ tier One lithium iron phosphate cells for its solar batteries.
For 48V inverters, compatible brands include Victron Energy, Goodwe, Studer, Solis, LuxPower, and others. For high-voltage three-phase inverters, compatible brands include Atess, Solinteg, SAJ, Goodwe, and Solis.
CMX Battery offers dealer customers a 10-year warranty and technical service for its energy storage battery products.
DoD describes how much of the battery's capacity has been used. A DoD of 100% means the battery is completely empty, while 0% means it is full.
SoC reflects the battery's charge level. A SoC of 100% means the battery is full, and 0% means it is empty.
C-rate, or power factor, indicates how quickly a battery can be charged or discharged relative to its capacity. A rating of 1C means the battery can be fully charged or discharged in one hour.
The battery uses Lithium Iron Phosphate chemistry and provides a cycle life of over 6,000 cycles at 90% Depth of Discharge, and over 10 years at one cycle per day.
kW (kilowatt) is a unit of power, measuring the rate of energy production or consumption. kWh (kilowatt-hour) is a unit of energy, measuring the total amount of work done or energy used over time.
CMX Battery home batteries are suitable for both indoor and outdoor installation (depending on the model's protection level) and offer floor-standing or wall-mounted options. Common locations include garages, attics, or under eaves.
This depends on the load. As a realistic example, a 10kWh battery could run ten 100-watt light bulbs for 12 hours without recharging.
The number varies based on home size, energy consumption history, and personal goals (like which devices to run during an outage). For most systems, 2 or 3 batteries are installed. A detailed discussion of your needs is recommended for an accurate assessment.
Yes, it is possible, but it requires careful planning and significant investment. A true off-grid system needs a large enough solar array and sufficient battery storage to sustain your lifestyle. Cost and having an alternative energy source for when solar charging isn't possible are key considerations.
No. CMX Battery focuses on building long-term relationships with business partners like battery distributors, solar equipment dealers, and installation contractors worldwide, not direct sales to end consumers.
