Wall-mount 10KWh 51.2V 200Ah Lithium LiFePO4 solar home battery
EG-Wall-mounted 10KWh Lithium Powerwall Energy Storage System
The EG-Wall-mounted 10KWh is a compact, high-performance lithium powerwall energy storage system, specifically engineered to meet the demands of modern household solar energy storage. Built with 51.2V 200Ah Lithium LiFePO4 cells, it delivers a total capacity of 10.24kWh, providing reliable backup power, energy independence, and improved solar self-consumption efficiency.
Designed for versatility, this wall-mounted battery system features sleek hidden wiring, app-based real-time monitoring, and supports parallel expansion up to 327.68kWh (32 units), making it ideal for both small residential setups and larger scalable systems. Whether installed indoors or outdoors, it offers a perfect blend of safety, performance, and aesthetics—helping homeowners take control of their energy future with confidence.
EG-Wall-mount 10KWh Lithium Powerwall Energy Storage System
The EG-wall-mount 10KWh is a 51.2V 200Ah wall-mounted Li-ion battery with a total capacity of 10.24kWh. It supports up to 32 modules in parallel with a maximum capacity of 327.68kwh and is designed for residential and commercial energy storage. It seamlessly integrates with existing home solar panel systems, storing excess power during the day and discharging it at night for energy self-sufficiency.
This 10 kWh powerwall battery is IP65-rated for use in harsh environments such as outdoor solar energy storage systems, telecommunication sites, construction sites, and industrial facilities. The protection ensures the stable operation of the battery regardless of heavy rain, snow, or dusty environments and meets the needs of home, commercial, and industrial energy storage.
Key Features
10KWh High-Efficiency Energy Storage
This 10kWh wall-mount power wall stores energy from your solar panels during the day and discharges it at night, allowing households to optimize their power usage and reduce reliance on the grid.
Nominal Voltage: 51.2V
Capacity: 200Ah
Energy: 5.12 kWh
Chemistry: Lithium Iron Phosphate (LiFePO4)
Wall-Mounted Design with Hidden Wiring
The EG 10.24KWh powerwall features a wall-mounted installation with a rear-concealed wiring layout that enhances the overall look and improves safety by reducing exposed cables. It also supports floor mounting for added flexibility.
Dimensions: 760*530*190 mm; Weight: 90kg；Installation: Wall-mounted or floor-mounted
Built for Residential Solar Storage
Seamless Integration with Household Solar Systems
Whether your home uses DC-coupled or AC-coupled solar setups, this lithium wall-mounted energy storage system connects effortlessly. It’s compatible with newly installed systems and retrofitted solar applications alike.
Perfect for Household Energy StorageEngineered to meet residential power demands, the 10KWh system ensures homes have reliable access to clean energy—even during outages or nighttime use. It’s ideal for:
Daily self-consumption of solar power
Emergency power backup
Load shifting and peak shaving
Smart, Safe & Scalable
LiFePO4 Safety and Longevity
Built with high-quality LiFePO4 lithium cells, this wall-mounted battery provides:
Over 6000 life cycles at 25°C
A design life of over 15 years
High thermal and chemical stability
IP65-rated protection for indoor and outdoor environments
Wi-Fi Monitoring
Built-in Wi-Fi connectivity and user-friendly app setup allow easy monitoring and control of your 10KWh wall-mounted lithium battery, giving homeowners full visibility into energy storage status.
Future-Proof Modular Design
Expandable up to 163.84 kWh
As your energy needs grow, the EG wall-mounted lithium powerwall can scale with you. Up to 32 units can be connected in parallel, supporting both household and light commercial applications.
Parallel Expansion: Up to 32 modules
Maximum Capacity: 327.68 kWh
Energy-Dense, Space-Saving Solution
With an energy density of 106Wh/kg, the compact design ensures that more power is delivered in less space—perfect for homes with limited installation areas.
Compatible with most brands of inverters
Designed for seamless integration, this battery is compatible with most 48V hybrid inverter brands, ensuring wide system compatibility and easy installation.
Specifications:
Send Inquiry:
If you’re looking for a 48V 200Ah wall-mounted home energy storage system with an actual capacity of 10.24kWh — lightweight easy to install and maintain, and with a sleek design the Wall-mount 10KWH Solar power system is the ideal choice.
Whether for personal use or wholesale, its outstanding quality and factory-direct pricing make it a smart investment. Don’t hesitate to send us an inquiry, our sales team will get back to you promptly.
You must be logged in to post a review.
Product & Packaging Details
Q: Do batteries include protection circuits（BMS) and connectors?
A:Protection: We supply batteries with BMS built in Protection Circuit Modules (PCM).
Connectors: We normally use standard like anderson,M8 lugs,Fast plugs or depends on OEM customer's demends.
Q: Are batteries Grade-A and brand new?
A: Yes, we use 100% brand new, Grade-A cells in all our batteries.
Q: Can you print our logo on the batteries?
A: Yes, we offer free custom logo printing with a minimal MOQ requirement.
Q: What is your standard packaging? Can it be customized?
A: Our standard is a white box per battery. We fully support customized packaging, including carton box and logo design.
Yes. EGbatt is a manufacturer located in Shenzhen, Guangdong, China. It designs and produces LiFePO4 battery packs for energy storage, electric forklifts, marine applications, golf carts, RVs, and UPS systems.
Based on automated production technology, the current product lead time is 15-25 days.
The company has strategic cooperation agreements with top manufacturers like EVE and REPT, and insists on using A+ tier One lithium iron phosphate cells for its solar batteries.
For 48V inverters, compatible brands include Victron Energy, Goodwe, Studer, Solis, LuxPower, and others. For high-voltage three-phase inverters, compatible brands include Atess, Solinteg, SAJ, Goodwe, and Solis.
EGbatt offers dealer customers a 10-year warranty and technical service for its energy storage battery products.
DoD describes how much of the battery's capacity has been used. A DoD of 100% means the battery is completely empty, while 0% means it is full.
SoC reflects the battery's charge level. A SoC of 100% means the battery is full, and 0% means it is empty.
C-rate, or power factor, indicates how quickly a battery can be charged or discharged relative to its capacity. A rating of 1C means the battery can be fully charged or discharged in one hour.
The battery uses Lithium Iron Phosphate chemistry and provides a cycle life of over 6,000 cycles at 90% Depth of Discharge, and over 10 years at one cycle per day.
kW (kilowatt) is a unit of power, measuring the rate of energy production or consumption. kWh (kilowatt-hour) is a unit of energy, measuring the total amount of work done or energy used over time.
EGbatt home batteries are suitable for both indoor and outdoor installation (depending on the model's protection level) and offer floor-standing or wall-mounted options. Common locations include garages, attics, or under eaves.
This depends on the load. As a realistic example, a 10kWh battery could run ten 100-watt light bulbs for 12 hours without recharging.
The number varies based on home size, energy consumption history, and personal goals (like which devices to run during an outage). For most systems, 2 or 3 batteries are installed. A detailed discussion of your needs is recommended for an accurate assessment.
Yes, it is possible, but it requires careful planning and significant investment. A true off-grid system needs a large enough solar array and sufficient battery storage to sustain your lifestyle. Cost and having an alternative energy source for when solar charging isn't possible are key considerations.
No. EGbatt focuses on building long-term relationships with business partners like battery distributors, solar equipment dealers, and installation contractors worldwide, not direct sales to end consumers.
EGBATT Battery Compatibility with Inverters
Perfect Matching with Mainstream Hybrid and On-grid Inverters
EGBATT lithium battery systems are tested for seamless compatibility with a wide range of inverter brands across global markets. Whether for residential, commercial, or utility-scale applications, our batteries support multiple communication protocols (CAN/RS485) and work with both low-voltage (40–60V) and high-voltage (100–1500V) inverter platforms.
- Low-Voltage System Compatibility (40–60V)
Low-voltage systems typically operate in the 48V-60V range and are widely used in home off/grid-connected solar systems. EGBATT lithium batteries offer seamless compatibility with a wide range of leading inverter brands in this range, including:
Deye, Growatt, GoodWe, ZZPower, Solis, Sinexcel, SRNE, Schneider Electric, Megarevo, AISWEI, SMA, Luxpower, Victron Energy, Afore, Hoymiles, INVT, Sofar, OutBack Power, SolaX Power, tbbpower, Sacolar, Sunsynk, Sosen, SMD Solar, Must, SOROTEC, Sunman, Voltronic Power, SAJ, and more. - High-Voltage System Compatibility (100–1500V)
High-voltage energy storage systems generally operate in the voltage range of 150V-1000V and are adapted to high-power inverters for commercial and industrial energy storage systems (80kWh-200kWh and above). EGBATT high-voltage lithium battery systems are fully compatible with leading inverter brands within this range, including:
Sol-Ark, INVT, Sinexcel, Luxpower, SClinTeg, Shanghai Nenergy, Deye, Growatt, Xina Electric, Hoymiles, Sunsynk, Hopewind, Solis, SOSEN, Megarevo, EcoCod, GoodWe, Sunways, Jingshi Technology, Kehua Tech, AISWEI, KOYOE, Sermatec, Afore, and more.
We offer integration support and testing for most mainstream hybrid and on-grid inverters. Contact EGBATT for compatibility details and custom solutions.
