# How many batteries do I need to run a 5000w inverter?

To power a 5000W inverter, you have to consider more than just the number of batteries. The battery capacity, the inverter voltage input and how long you need to use the inverter are important. Large inverters are used as emergency power backup, so determine how many hours the system will run. The formula is hours needed x watts = total watts / volts = battery amps.

A 5000W inverter requires at least one 450-500ah 12V battery or two 210ah 12V batteries to run for 30-45 minutes. A 750ah 12V battery is needed to run the inverter for 1 hour. A 2500ah battery is required for a 4 hour discharge time. You have to double the capacity for each if you don’t want to discharge the battery at 100%.

## Batteries For Inverter Calculation

To illustrate further, suppose you bought a 5000W inverter with a 12V input. If you use the inverter’s full capacity, that is 416 amps an hour. (5000W / 12V = 416). Theoretically a 450-500ah battery can run the system for an hour. But inverters are not perfect and some energy is lost, so more likely it is 30-45 minutes. Of course the figure will be different if you have a 24V, 36V or 48V battery.

However that figure supposes you will run the battery down to zero, or a 100% discharge. We have stated in other posts on this site that lead acid batteries should be recharged at 50%. So you need at least a 750ah-800A battery to run the inverter for 30-45 minutes without totally depleting the battery.

No matter what the voltage is, the ah rating in series configured batteries will always be that of the smallest battery in the setup. Multiple batteries increases voltage so the power supplied (in watts) increases.

With four 210ah 48V batteries, the inverter receives 104ah hourly. With a full discharge the inverter can run at maximum load for two hours or 10kwh (10,000W). Bottom line: no matter what the battery bank voltage, it must provide 5000W for every hour you want the inverter to operate.

## Battery Size For Inverter Chart

This chart shows how much power is required for different types of inverters. This table assumes you’ll be using the battery to full capacity. Double the capacity for each column if you’re going to recharge the battery at 50%. The optimum capacity is for a four hour discharge, and the minimum is for one hour.

Inverter Output in Watts Optimum Capacity Minimum Capacity
500 200AH 80AH
1000 400AH 150AH
1500 700AH 240AH
2000 1000AH 300AH
3000 1500AH 450AH
4000 2000AH 600AH
5000 2500AH 750AH

Again, the DOD (depth of discharge) here is close to 100%. You can do that with lithium batteries but for lead acid the DOD is at 50%. These inverter and battery sizes are common for solar powered homes. They are less frequent in RVs except for the really large ones. Make sure the capacity is suitable for your camper before buying.

## How To Find The Right Battery Inverter Size

The calculations above are useful if you want a general idea of how much power you need. But if you want to be more specific, follow these steps.

5000W is a lot of power but do you really need that inverter size? The best way to find out is to add up the total watt usage of all your loads. Include every appliance and device you plan to run on the inverter. Do note that refrigerators and air conditioners have surge requirements so a large system is definitely required.

### 2. Check The Inverter Input Voltage

A lot of inverters have 12V or 24V input, but 36V, 48V and even 96V and others are not uncommon. Make sure your battery matches the input. The battery doesn’t have to be a specific match as long as the total is the same. Example, a 48V inverter will work with a 12V battery if you have four hooked up (12 x 4 = 48).

### 3. Determine How Many Hours You Need To Run The Inverter

This is crucial. How long do you plan to run the inverter? Is it for a couple of hours? 5 hours? 12 hours or more? This tells you how many watt hours you need and how much the battery capacity has to be.

Suppose your 5000W, 48V inverter needs to run for 6 hours. If the power load factor is 0.8 then the volt amperes (VA) is 130 amperes. Your battery must be able to provide minimum 130 amperes. 48V 130 ampere batteries are uncommon so you may opt for a 200 amperes instead.

### 4. Calculate Battery Storage Capacity

Battery capacity is measured in amp hours (ah). With our example here you need four 200ah-220ah batteries. That should be sufficient to run a 5000W inverter for 8 hours more or less.

These steps are best suited for homes that need a large power backup. For RVs, the needs are usually smaller and the calculations more straightforward.

## Calculate Battery Size For Inverter For RVs

For RVs it is much simpler. Add the total watt consumption of every device you will run and divide it by 12. 12 is for the voltage which most RVs use. If the total is near 5000W then a you need a 460ah-500ah battery. If not, a smaller inverter will do.

Most RVers have a solar generator to power their devices. If you have a solar panel installed you probably don’t need such a large inverter. While a solar generator can power a refrigerator, most RVers use a mini fridge to save power.

You will need more than 5000W if you decide to run an AC though. Powering an air conditioner for 10 hours is about 7000W. You need a 640ah battery minimum. At a 50% depth of discharge that is almost 1300ah or thirteen 100ah batteries This is why you rarely see RVers use solar power for refrigerators or AC units unless it is a compact version. They just consume too much power that could otherwise be used for other appliances.

## Battery Overhead And Discharge Rate

Technically , 416 amps is sufficient for 5000W, but add another 50W for overhead so it’s 460. So 460ah or better yet 500ah will operate an inverter without any problems. A faster discharge rate erodes the battery bank’s life cycle. A slower discharge rate does the opposite.

A 460ah battery bank keeps the inverter running for 30 minutes at a full 5000W. Lowering the inverter load prolongs the battery life. Reduce the load from 5000W to 3000W and the battery will last an hour or so. You can do this with any inverter, but do so only if it’s practical. If you calculated your total load requirement and realized you don’t need to use that many, load reduction will help the battery.

## Should Inverter Batteries Be In A Series Or Parallel Connection?

It depends on the inverter. Check your inverter installation guide and it will tell you whether to configure the batteries in series or parallel. Both connections have the same purpose, increase power that goes in the inverter. Whether it is series or parallel, the input power will be similar. Current x voltage = input power. A series or parallel configuration will not change that.

However, connecting batteries in a series has some advantages. You can use smaller wires, reducing energy loss. A parallel connection means each battery has a unique internal resistance. The long and short of it is this leads to unequal power distribution in the system.

However there are cases where a parallel setup may be better. You can find more information in your inverter’s installation manual. You may also find relevant information in your battery’s product guide.

## Other Points To Consider

These are large numbers so you need to plan ahead before committing to buy. To recap here are the biggest points you should bear in mind.

• The inverter capacity
• The inverter DC input voltage
• The load you will supply to the inverter
• Most 5000W inverters have a 24V or 48V input. You can buy 48V batteries or any battery volt as long as the total is 48.
• Do not let lead acid battery discharges drop below 50%. When calculating battery sizes for inverters, assume that you will use only 50% of the battery capacity.
• The battery capacity determines how long the inverter can run. This is important if you will use the inverter as a backup power system.
• A tubular battery is better suited for an inverter than flat plate batteries.

## Conclusion

The inverter is one of the most important parts of a solar system. If it is too small the system will not run. If it is too big the batteries will not be optimized. By knowing how many batteries are needed, and the right specs, you’ll have no issues running solar power to the maximum potential.

How long does a lithium iron phosphate battery last?2020-11-18T17:02:14+00:00

## How long does a lithium iron phosphate battery last?

Different from any other Lithium ion batteries. Lithium Iron Phosphate battery with less active chemical. A regular Lithium iron phosphate battery will last up to 3000 cycles at 80% DOD. The average lifetime of lead-acid batteries is just two years. When make a battery pack. The battery life should get a 90% discount.
Difference between Power Battery and Energy Storage Battery2019-12-30T14:20:45+00:00

# The difference between power batteries and energy storage batteries

## The internal resistance of battery power battery with the same capacity is less than that of energy storage battery.

The internal resistance of battery power battery with the same capacity is less than that of energy storage battery.

Power batteries are generally used in devices requiring high current discharge (3C-5C), and energy storage batteries are used in devices requiring low current discharge (generally 0.5-1C range).

Batteries of the same capacity will weigh heavier than energy storage batteries (different design processes).

Different prices. The price of power batteries will be more than 1.5 times higher than that of energy storage (according to the different requirements of customers) power batteries and energy storage batteries are defined broadly, which kind do you refer to from the application point of view? Energy storage batteries generally have low current and belong to energy type. Power batteries generally need to discharge 3C. The discharge capacity, discharge curve and platforms can be compared by 3C discharge or 1.5C discharge. The price is expected to be 1.2 times higher than that of the latter for the same specifications.

What is Ternary NCM Lithium Battery2021-02-09T13:01:08+00:00

# About NCM ternary lithium battery

Most of the ternary materials are NCM. In general, the term “ternary lithium battery” refers to NCM. The representative manufacturers of NCM abroad are SDI and SKI. Tesla uses NCA18650, which has relatively strong stability and cyclic performance. However, in the manufacturing process, because Al is amphoteric metal, it is not easy to precipitate, so there is a threshold in the process. Because the content of aluminium in NCA is too small, it is often called binary material.

The NCM product model of ternary materials ranges from 111 ternary (N:C:M=1:1:1) to 433,532,622,811. With the increase of nickel content, the energy density of the battery was increased accordingly.

Lithium batteries refer to a wide range of large categories, all used in lithium materials can be called lithium batteries. According to the scientific name, we usually say that lithium batteries should be called lithium ion batteries/lithium secondary batteries, with corresponding negative electrode materials.

The cathode materials of lithium ion batteries are mainly LiCoO 2, LiMnO 4, LiCox NiyMnzO 2, ternary materials and LiFePO4. The cathode uses ternary materials called ternary lithium batteries.

The main advantage of ternary lithium battery is that its energy density is higher than that of other materials.

The cathode materials of ternary lithium batteries are divided into NCA nickel cobalt aluminium and NCM nickel cobalt manganese.

what is lithium iron phosphate battery2019-11-22T14:33:55+00:00

## What is a lithium iron phosphate battery?

lithium iron phosphate battery is also a rechargeable type of battery but made with lithium iron phosphate (LiFePO4) as the cathode material.

While lithium-iron is a newer version in the lithium battery family, its anodes are also made up of carbon in batteries.

Phosphate based technology possesses superior thermal and chemical stability which provides better safety characteristics than those of Lithium-ion technology made with other cathode materials. Lithium phosphate cells are incombustible in the event of mishandling during charge or discharge, they are more stable under overcharge or short circuit conditions and they can withstand high temperatures without decomposing. When abuse does occur, the phosphate based cathode material will not burn and is not prone to thermal runaway. Phosphate chemistry also offers a longer cycle life.

## lithium iron phosphate battery

The lithium-iron (LiFePo4) battery has a slight edge over the Li-ion (LiCoO2) battery for safety. This is important because a battery should not get overheated or catch fire in case of overcharging.

The lithium-iron battery has superior chemical and thermal stability. A Lithium-iron battery remains cool at room temperature while the Li-ion may suffer thermal runaway and heats up faster under similar charging conditions.

LiFePO4 is a nontoxic material, but LiCoO2 is hazardous in nature, so is not considered a safe material. Disposal of Li-ion battery is a big concern for the manufacturer and user. .
